PRONTO PANEL

SYSTEM COMPONENTS

Pronto Panel Low Rise Intertenancy Wall

Used:
– In the tongue and groove to 20kg
bond adjacent panels.
– In the horizontal joint for
Pronto Panel vertically stacked panels.
Adhesive – Optionally applied between the Yes
slab and the base of the Pronto
Panel.
Fire Rated Sealant may be used for
the same purpose.

Used:
– In the tongue and groove to
bond adjacent panels.
– In the horizontal joint for Yes
Bostik vertically stacked panels.
Fireban One (only in Pronto
– Optionally applied between the Accessory Boxes)
slab and the base of the Pronto
Panel. Pronto Panel Adhesive
may be used for the same
purpose.

Brickworks supplies Accessory Boxes with the necessary components (excluding Pronto Panel Adhesive)
to construct 10 or 25 square meters of straight wall and Corner Accessory Boxes with components for
constructing 2 corners. Accessory Boxes are available for timber and steel frames.
Timber Frame Accessory Boxes
Components 10m 2 25m 2 2 Corners
12g x 35mm T17 Hex 140 330 60

Pronto L Bracket 32 80 15
14g x 200mm T17 Bugle 5 15 22
12g x 50 T17 Hex 30 70 -
Fireban One 1 1 2

Steel Frame Accessory Boxes
Components 10m 2 25m 2 2 Corners

12g x 35mm T17 Hex 70 170 30
12g x 20mm T17 Hex 70 170 30
10g x 16mm Button Tek 100 200 60
Pronto L Bracket 32 80 15
14g x 200mm T17 Bugle 5 15 22
12g x 50 T17 Hex 30 70 -
Fireban One 1 1 2
